关于如何确定石英晶振中峰与峰之间的抖动,Cardinal晶振已确定精确测量晶体振荡器的抖动，在OR处低于1皮秒，这是目前唯一的方法,可用于测量石英晶振相位噪声并计算有效值抖动。请参阅我们的应用说明“晶体振荡器用于低抖动应用“的完整解释。测量晶体振荡器的相位噪声，我们使用双源方法。这导致单个1Hz带宽内相位的边带测量在特定偏移频率范围内。单边带相位噪声结果为在指定的频率带上积分，通常为10Hz至1MHz或12kHz至20MHz，具体取决于应用程序。SONET要求带宽为12kHz至20MHz。此频域集成相位噪声（以dBc/Hz为单位）然后转换为时间,RMS抖动（以皮秒为单位）。
在Cardinal晶振的非PLL振荡器中，RMS抖动具有随机高斯分布，因为没有使用锁相环路。这个结果在缺乏离散杂散和多模态的情况下非高斯分布。因此，很少或没有由低噪声供电时的确定性抖动电源。当抖动具有高斯时响应，RMS抖动是标准差或一个西格玛值。
基本组件中使用的石英晶体振荡器具有非常高的Q值。加载的Q的振荡器谐振器环路在10，000到超过100，000。当振荡器级产生信号，频率可以驻留在振荡带宽。但是，对于高Q谐振器实现窄振荡带宽、振荡器可以制造出非常低的抖动。
基数抖动的高斯分布组件振荡器，周期的平均值位于高斯曲线的中心。标准偏差（1西格玛）定义为包含发生的总振荡的68.26%。这窗口放置在均值的一侧。1西格玛（标准偏差）值是振荡器输出信号。作为标准的数量偏离均值增加，几率振荡器产生该周期偏差的信号大大减少。在14.069西格玛时，概率为1：1012.光纤通道规格要求14西格玛可靠性。
Cardinal晶振确定峰到峰（Pk到Pk）值取决于关于所需的可靠性。可靠性越高,Pk到Pk值越大，即使发生概率随着更高的西格玛值。在14西格玛时，概率接近1：1012.这被认为是我们用来确定的标准RMS抖动值的Pk到Pk抖动。如果组件振荡器具有2皮秒RMS抖动，Pk到Pk抖动为28皮秒。

制造商零件编号	制造商	系列	频率	频率稳定性	频率容差	负载电容
CSM4Z-A2B3C3-40-12.0D18	Cardinal晶振	CSM4	12 MHz	±30ppm	±30ppm	18pF
CSM1Z-A5B2C3-40-14.7456D20	Cardinal晶振	CSM1	14.7456 MHz	±50ppm	±30ppm	20pF
CSM1Z-A0B2C3-100-5.0D18	Cardinal晶振	CSM1	5 MHz	±50ppm	±30ppm	18pF
CSM1Z-A5B2C5-40-14.7456D18	Cardinal晶振	CSM1	14.7456 MHz	±50ppm	±20ppm	18pF
CSM1Z-A2B2C3-40-30.0D18	Cardinal晶振	CSM1	30 MHz	±50ppm	±30ppm	18pF
CSM4Z-A2B3C3-60-6.0D18	Cardinal晶振	CSM4	6 MHz	±30ppm	±30ppm	18pF
CX325Z-A5B2C5-50-20.0D18	Cardinal晶振	CX325	20 MHz	±50ppm	±20ppm	18pF
CSM4Z-A2B3C3-40-10.0D18	Cardinal晶振	CSM4	10 MHz	±30ppm	±30ppm	18pF
CSM4Z-A2B3C3-40-29.49152D18-F	Cardinal晶振	CSM4	29.49152 MHz	±30ppm	±30ppm	18pF
CSM1Z-A0B2C3-50-15.360D18	Cardinal晶振	CSM1	15.36 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-50-16.257D18	Cardinal晶振	CSM1	16.257 MHz	±50ppm	±30ppm	18pF
CSM1Z-A5B2C5-40-11.0592D18	Cardinal晶振	CSM1	11.0592 MHz	±50ppm	±20ppm	18pF
CSM1Z-A0B2C3-50-18.0D18	Cardinal晶振	CSM1	18 MHz	±50ppm	±30ppm	18pF
CSM1Z-A5B2C3-120-6.144D18	Cardinal晶振	CSM1	6.144 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-80-13.5D18	Cardinal晶振	CSM1	13.5 MHz	±50ppm	±30ppm	18pF
CSM1Z-A5B2C3-40-14.31818D18	Cardinal晶振	CSM1	14.31818 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-50-22.1184D18	Cardinal晶振	CSM1	22.1184 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-150-4.9152D18	Cardinal晶振	CSM1	4.915 MHz	±50ppm	±30ppm	18pF
CSM1Z-A5B2C5-150-3.6864D18	Cardinal晶振	CSM1	3.6864 MHz	±50ppm	±20ppm	18pF
CSM1Z-A0B2C3-100-7.3728D18	Cardinal晶振	CSM1	7.3728 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-50-25.175D18	Cardinal晶振	CSM1	25.175 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-50-28.63636D18	Cardinal晶振	CSM1	28.63636 MHz	±50ppm	±30ppm	18pF
CSM1Z-A5B2C3-60-9.216D18	Cardinal晶振	CSM1	9.216 MHz	±50ppm	±30ppm	18pF
CSM1Z-A5B2C3-120-6.0D18	Cardinal晶振	CSM1	6 MHz	±50ppm	±30ppm	18pF
CSM4Z-A2B3C3-40-26.0D18-F	Cardinal晶振	CSM4	26 MHz	±30ppm	±30ppm	18pF
CSM1Z-A0B2C3-50-24.0D18	Cardinal晶振	CSM1	24 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-80-10.0D18	Cardinal晶振	CSM1	10 MHz	±50ppm	±30ppm	18pF
CSM1Z-A5B2C3-40-12.0D18	Cardinal晶振	CSM1	12 MHz	±50ppm	±30ppm	18pF
CSM1-A1B2C3-50-20.0D16	Cardinal晶振	CSM1	20 MHz	±50ppm	±30ppm	16pF
CSM1Z-A0B2C3-100-6.144D18	Cardinal晶振	CSM1	6.144 MHz	±50ppm	±30ppm	18pF
CSM1Z-A1B2C3-90-8.0D18	Cardinal晶振	CSM1	8 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-80-12.0D18	Cardinal晶振	CSM1	12 MHz	±50ppm	±30ppm	18pF
CSM4Z-A2B3C3-180-4.0D18	Cardinal晶振	CSM4	4 MHz	±30ppm	±30ppm	18pF
CSM1Z-A5B2C5-60-8.0D18	Cardinal晶振	CSM1	8 MHz	±50ppm	±20ppm	18pF
CSM1Z-A5B2C3-60-8.0D18	Cardinal晶振	CSM1	8 MHz	±50ppm	±30ppm	18pF
CSM1Z-A5B2C5-60-24.0D18	Cardinal晶振	CSM1	24 MHz	±50ppm	±20ppm	18pF
CSM1Z-A5B2C5-50-20.0D18	Cardinal晶振	CSM1	20 MHz	±50ppm	±20ppm	18pF
CSM4Z-A2B3C3-60-8.0D18	Cardinal晶振	CSM4	8 MHz	±30ppm	±30ppm	18pF
CSM4Z-A2B3C3-40-25.0D18-F	Cardinal晶振	CSM4	25 MHz	±30ppm	±30ppm	18pF
CX5Z-A5B2C5-40-24.0D18	Cardinal晶振	CX5	24 MHz	±50ppm	±20ppm	18pF
CX5Z-A1B2C5-40-24.0D18	Cardinal晶振	CX5	24 MHz	±50ppm	±20ppm	18pF
CX5Z-A5B2C5-50-16.0D18	Cardinal晶振	CX5	16 MHz	±50ppm	±20ppm	18pF
CX5Z-A5B2C5-40-27.0D18	Cardinal晶振	CX5	27 MHz	±50ppm	±20ppm	18pF
CX5Z-A0B2C5-50-16.0D18	Cardinal晶振	CX5	16 MHz	±50ppm	±20ppm	18pF
CX5Z-A2B2C5-40-10.0D18	Cardinal晶振	CX5	10 MHz	±50ppm	±20ppm	18pF
CX532Z-A2B3C5-70-1966080D18	Cardinal晶振	CX532	19.6608 MHz	±30ppm	±20ppm	18pF
CX532Z-A2B3C5-70-33.0D18	Cardinal晶振	CX532	33 MHz	±30ppm	±20ppm	18pF
CX532Z-A5B3C5-70-27.0D18	Cardinal晶振	CX532	27 MHz	±30ppm	±20ppm	18pF
CX532AZ-A5B2C5-70-25.0D18	Cardinal晶振	CX532	25 MHz	±50ppm	±20ppm	18pF
CX532Z-A2B3C5-70-27.0D18	Cardinal晶振	CX532	27 MHz	±30ppm	±20ppm	18pF
CX532Z-A2B3C5-70-30.0D18	Cardinal晶振	CX532	30 MHz	±30ppm	±20ppm	18pF
CPFBZ-A2C4-32.768KD6	Cardinal晶振	CPFB	32.768 kHz	-	±10ppm	6pF
CPFBZ-A2C5-32.768KD12.5	Cardinal晶振	CPFB	32.768 kHz	-	±20ppm	12.5pF
CPFBZ-A2C4-32.768KD12.5	Cardinal晶振	CPFB	32.768 kHz	-	±10ppm	12.5pF
CPFBZ-A2C5-32.768KD6	Cardinal晶振	CPFB	32.768 kHz	-	±20ppm	6pF
CX532Z-A2B3C5-70-8.0D18	Cardinal晶振	CX532	8 MHz	±30ppm	±20ppm	18pF
CX532Z-A2B3C5-70-16.0D18	Cardinal晶振	CX532	16 MHz	±30ppm	±20ppm	18pF
CX532Z-A2B3C5-70-12.0D18	Cardinal晶振	CX532	12 MHz	±30ppm	±20ppm	18pF
CX5Z-ARB2C5-70-7.3728D18	Cardinal晶振	CX5	7.3728 MHz	±50ppm	±20ppm	18pF
CX5Z-A2B2C5-70-8.0D18	Cardinal晶振	CX5	8 MHz	±50ppm	±20ppm	18pF
CSM1Z-A0B2C3-70-14.7456D18	Cardinal晶振	CSM1	14.7456 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-50-16.000312D18	Cardinal晶振	CSM1	16.000312 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-50-16.0D18	Cardinal晶振	CSM1	16 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-50-17.734475D18	Cardinal晶振	CSM1	17.734475 MHz	±50ppm	±30ppm	18pF
CSM1Z-A0B2C3-80-11.0592D18	Cardinal晶振	CSM1	11.0592 MHz	±50ppm	±30ppm	18pF
CSM1-A1B2C3-70-14.7456D20	Cardinal晶振	CSM1	14.7456 MHz	±50ppm	±30ppm	20pF
CSM1Z-A1B2C3-200-3.6864D20	Cardinal晶振	CSM1	3.6864 MHz	±50ppm	±30ppm	20pF
