欧美晶振
- 产品型号：92191852
- 晶振频率：32.768KHz
- 晶振尺寸：
- 产品应用： 欧美进口晶振,Geyer晶振,KX-327XS音叉晶体,12.87123晶振,晶体谐振器,4918mm晶振,贴片石英晶振,二脚贴片晶振,频率32.768KHz,负载6.0pF,频率容差30ppm,工作温度-20~70°C,小体积晶振,高品质晶振,耐老化晶振,音频系统晶振...
-
12.87123|32.768KHz|6.0pF|Geyer音叉晶体
12.87123|32.768KHz|6.0pF|Geyer音叉晶体,欧美进口晶振,Geyer晶振,KX-327XS音叉晶体,12.87123晶振,晶体谐振器,4918mm晶振,贴片石英晶振,二脚贴片晶振,频率32.768KHz,负载6.0pF,频率容差30ppm,工作温度-20~70°C,小体积晶振,高品质晶振,耐老化晶振,音频系统晶振,数字设备晶振,智能家居应用晶振,儿童游戏机晶振.
12.87123|32.768KHz|6.0pF|Geyer音叉晶体规格表
| part no. | 12.87123 |
| model | KX-327XS |
| frequency | 32.768 kHz |
| operating temperature | -20°~+70℃ |
| frequency tolerance(df/F) at +25°C ±3°C | 土30ppm |
| temperature tolerance (parabolic coefficient) |
-0.034 ±0.006 ppm / °C2 typ
|
| turnover temperature | +25°C±5°℃ |
| storage temperature range | -55°C~+125℃ |
| load capacitance CL | 6.0 pF |
| shunt capacitance C0 max. | 2 pF |
| series resistance R1 (ESR) max. | 65 KOhm |
| aging at +25°℃ (first year) max. | ±3 ppm |
| drive level | 1 μW max. |
| contents of reel | 3000 pcs. |
.jpg)
12.87123|32.768KHz|6.0pF|Geyer音叉晶体尺寸图
