欧美晶振


12.61010|32.4MHz|8pF|Geyer Crystal,Geyer Crystal,KX-3T无源晶振,进口贴片晶振,12.61010晶振,1210mm晶振,石英晶体谐振器,SMD晶振,四脚封装晶振,频率32.4MHz,负载8pF,频率容差30ppm,工作温度-40~85°C,超小型晶振,高稳定性晶振,高质量晶振,无线局域网晶振,蓝牙耳机晶振,音频系统晶振,通讯设备晶振.


12.61010|32.4MHz|8pF|Geyer Crystal规格表
part no. | 12.61010 |
model | KX-3T |
frequency range | 32.4MHz |
mode |
fundamental |
operating temperature | -40~+85℃ |
frequency tolerance at +25°C | 土30 ppm |
temperature tolerance |
土30 ppm
|
storage temperature range | -55°C~+125℃ |
load capacitance CL | 8 pF |
shunt capacitance C0 max. | 3.0 pF |
series resistance R1 (ESR) max. | 150 Ohm |
aging at +25°℃ (first year) max. | ±2 ppm |
drive level | 50 μW max. |
contents of reel | 1000 /3000pcs. |
.jpg)

12.61010|32.4MHz|8pF|Geyer Crystal尺寸图
